ZCP21M12 | Limit switch body, Limit switches XC Standard, ZCP, compact, 1NC+1 NO, snap action, M12 4P | SQUARE D

The photo is for representation purposes only and may not be a photo of product being purchased.

Search products similar to ZCP21M12

Jump to: Documents Overview Specifications Reviews

Documents and manuals

SQUARE D ZCP21M12 Documents

More Info

Overview

Details for ZCP21M12

NCO ZCP21M12 Square D 24VAC 4A Limit Switch The NCO ZCP21M12 from Square D is a heavy-duty limit switch that combines precision sensing with rugged construction. Its 24VAC operating voltage and 4A switching capacity make it suitable for demanding industrial applications. Engineered for durability, the NCO ZCP21M12 features a corrosion-resistant aluminum housing and a weatherproof design that withstands harsh environmental conditions. Its compact size and versatile mounting options ensure easy installation in confined spaces. Key features: * 24VAC operating voltage * 4A switching capacity * Corrosion-resistant aluminum housing * Weatherproof design * Compact and easy to install Applications: * Control and monitoring systems * Industrial machinery * Material handling * Process automation Maximize your industrial operations with the NCO ZCP21M12 Limit Switch. Contact our HVAC supply store today for competitive pricing and fast shipping! This ZCP body/contact assembly with connector has standard contacts and a plastic body. It has 1 x NO + 1 x NC snap action contacts and a M12 4-pin connector. It can be matched with any head, actuator or connector from the XCKD, XCKP and XCKT ranges.

Specifications

Range of Product: Telemecanique Limit switches XC Standard
Series name: Standard compact
Product or Component Type: Limit switch body
Device short name: ZCP
Design: Compact
Body type: Fixed
Associated head: ZCE63, ZCE06, ZCE21, ZCE24, ZCE09, ZCE29, ZCE67, ZCEH0, ZCE08, ZCE07, ZCE10, ZCEH2, ZCE62, ZCE02, ZCE11, ZCE05, ZCE14, ZCE64, ZCE28, ZCE01, ZCE66, ZCE13, ZCE65, ZCE27
Body Material: Plastic
Number of poles: 2
Contacts type and composition: 1 NC + 1 NO
Contact operation: Snap action
electrical connection: Male connector M12, 4 pins
Contacts insulation form: Zb
Contacts material: Silver plated contacts
Positive opening: With
Minimum actuation speed: 0.03 ft/s (0.01 m/s)
contact code designation: B300, AC-15 (Ue = 240 V), Ie = 1.5 A EN/IEC 60947-5-1 appendix A, R300, DC-13 (Ue = 250 V), Ie = 0.1 A EN/IEC 60947-5-1 appendix A
[Ui] rated insulation voltage: 300 VUL 508, 500 V 3)IEC 60947-1, 300 VCSA C22.2 No 14
maximum resistance across terminals: 25 mOhm IEC 60255-7 category 3
[Uimp] rated impulse withstand voltage: 6 kV IEC 60664, 6 kV IEC 60947-1
short-circuit protection: 10 A cartridge fuse gG
[Ie] rated operational current: 3 A 240 V, AC-15 EN/IEC 60947-5-1 appendix A, 0.27 A 250 V, DC-13 EN/IEC 60947-5-1 appendix A
[Ithe] conventional enclosed thermal current: 3 A
electrical durability: 5000000 cycles, DC-13 120 V, 4 W 60 cyc/mn 0.5 IEC 60947-5-1 appendix C, 5000000 cycles, DC-13 24 V, 10 W 60 cyc/mn 0.5 IEC 60947-5-1 appendix C, 5000000 cycles, DC-13 48 V, 7 W 60 cyc/mn 0.5 IEC 60947-5-1 appendix C
Width: 1.22 in (31 mm)
Height: 2.56 in (65 mm)
Depth: 1.18 in (30 mm)
Net Weight: 0.15 lb(US) (0.07 kg)
Product Compatibility: XCKP
ambient air temperature for operation: -13…158 °F (-25…70 °C)
Ambient Air Temperature for Storage: -40…158 °F (-40…70 °C)
Category: 22418-LIMIT SWITCH,IEC,XCKP&XCKT
Discount Schedule: T
GTIN: 3389110183962
Returnability: Yes
Country of origin: ID
Unit Type of Package 1: PCE
Number of Units in Package 1: 1
Package 1 Height: 1.30 in (3.3 cm)
Package 1 Width: 1.57 in (4 cm)
Package 1 Length: 3.82 in (9.7 cm)
Package 1 Weight: 2.43 oz (69 g)
Unit Type of Package 2: S02
Number of Units in Package 2: 77
Package 2 Height: 5.91 in (15 cm)
Package 2 Width: 11.81 in (30 cm)
Package 2 Length: 15.75 in (40 cm)
Package 2 Weight: 12.92 lb(US) (5.862 kg)
Warranty: 18 months
