4350-028 | BJWA Gas Gridlle Thermostat Kit | Robertshaw

The Robertshaw® 4350 Series Gas Thermostat is a combination gas cock and by-pass type thermostat. It is available with both by-pass and pilot adjustments. With these thermostats, the gas is turned on and the temperature setting made with a single turn of the dial. The 4350 Series is available for a wide variety of applications, especially ranges and griddles.

The photo is for representation purposes only and may not be a photo of product being purchased.

Search products similar to 4350-028

Jump to: Documents Overview Specifications Reviews

Documents and manuals

Robertshaw 4350-028 Documents

4350 Series Commercial Thermostat BJ Uni-kit® Manual BJWA Series / 4350 Series Gas Thermostats Sell Sheet 4350 Series Commercial Gas Thermostat Replacement Information 2019 Uni-Line Product Catalog in English 2019 Uni-Line Product Catalog in Spanish 2018 Uni-Line Product Catalog in Portuguese 2019 Uni-Line Product Catalog in French 2018 Uni-Line Product Catalog in German 2018 Uni-Line Product Catalog in Italian Robertshaw Comprehensive Global Solutions Robertshaw Soluciones Integrales Globales Robertshaw Soluções globais abrangentes Robertshaw Commercial Catalog 150-2634 More Info

Overview

Details for 4350-028

4350 Series Commercial Gas Thermostats

Highly adaptable because of multiple orientations and number of outlets
Mounted, via flange nipple, above or below the manifold
Available with various temperature ranges
Front adjustment for pilot and by-pass
Modulating seat action
Bulb and capillary available in copper, nickel plated copper and stainless steel

Specifications

Item Number	4350-028
Brand	Robertshaw
00-802116-00001	VULCAN HART/P M I
01021-9	MONTAGUE
03367-7	ALTO-SHAAM
10482	AMERICAN RANGE
1174337	SOUTH BEND RANGE
13032	DCS
13052	DCS
147904	FRANKLIN CHEF
147905	FRANKLIN CHEF
17039	COMSTOCK CASTLE
19297	PMI
19362	PMI
2116	VULCAN HART/P M I
227000-1	GARLAND
227000-SK	GARLAND
227000	GARLAND
28377	UNI-LINE
2T-39281	STAR MFG.CO.
2T-9493	STAR MFG.CO.
30603	AMERICAN RANGE
324793	METAL MASTERS
3367-7	ALTO-SHAAM
3384-7	MONTAGUE
4350-002	UNI-LINE
4350-003	UNI-LINE
4350-005	UNI-LINE
4350-006	UNI-LINE
4350-007	UNI-LINE
4350-009	UNI-LINE
4350-019	UNI-LINE
4350-020	UNI-LINE
4350-021	UNI-LINE
4350-026	UNI-LINE
4350-C028	UNI-LINE
4352-028	UNI-LINE
460-101-000	JADE RANGE INC.
55764-03	DCS
5928159282	WELLS MFG.
59281	WELLS MFG.
59282	WELLS MFG.
719362	PMI
723257	PMI
723258	PMI
80017-01	THERMATEK
802116-1	HOBART CORP
8202116	VULCAN HART/P M I
920028	HOBART CORP
9493	STAR MFG.CO.
9990-007	UNI-LINE
BJ	ROBERTSHAW
BJWA25PA-01-36	QUEST METAL
BJWA25PA-02-24	PMI
BJWA25PA-03-24	PMI
BJWA25PB-03-36	SOUTH BEND RANGE
BJWA25PC-02-48	DCS
BJWA25PC-02-48	ROBERTSHAW
BJWA25PC-04-36	COMSTOCK CASTLE
BJWA25PC-09-36	ROBERTSHAW
BJWA25PM-04-36	COMSTOCK CASTLE
BJWA25PM-05-36	METAL MASTERS
BJWA25PM-07-48	IAC
BJWA25PM-12-36	MONTAGUE
BJWA25PM-13-36	GARLAND
BJWA38PA-01-24	PMI
Capacity	70;000 BTU/HR Natural Gas
Capillary Length	36"
F16-119	JOHNSTONE SUPPLY
Flange Type	Wide
G023	AMERICAN CATERING
GT09	RANKIN DELUXE
Housing Rotated	No
K-101	RANCO
L032A	CECILWARE/COMMODORE
L032F	CECILWARE/COMMODORE
L032T	CECILWARE/COMMODORE
Main Outlet Position	A; B; C; D
Main Outlet(s) Size	1/4" Pipe
Maximum Inlet Pressure	0.5 PSI
Pilot Outlet	Yes
R99	MONTAGUE
Sensing Bulb	3/16" x 8-5/8"
Series Application	BJWA Kit for Griddles
Temperature Range	150°F to 400°F (66°C to 205°C)
Y-9493	STAR MFG.CO.
Y2353	STAR MFG.CO.
Z17677-24	ROBERTSHAW
Z56256-36	ROBERTSHAW
Z622500036	GARLAND
Z622500036	INVENSYS APPLIANCE CONTROLS
Z62253-36	ROBERTSHAW
Z622530036	INVENSYS APPLIANCE CONTROLS
Z622630024	STAR MFG.CO.
Z62291-0036	JADE RANGE INC.
Z622910036	JADE RANGE INC.
Z69021-36	UNI-LINE
Z69022-36	UNI-LINE
Z69024-36	ROBERTSHAW
Z83216-36	ROBERTSHAW
Z83234-36	ROBERTSHAW
Z84570-36	ROBERTSHAW
Z86181-36	ROBERTSHAW
Z891350036	GARLAND
Z891600036	SOUTH BEND RANGE
