GVD326.1U | Damper Actuator | Spring Return | 230 VAC | On/Off | 200 lb-in | SW | Siemens Building Technology

The photo is for representation purposes only and may not be a photo of product being purchased.

Search products similar to GVD326.1U

Jump to: Documents Overview Specifications Reviews

Documents and manuals

Siemens Building Technology GVD326.1U Documents

Datasheet(OpenAir GVD/GKD Electronic Damper Actuator US Listed Fire/Smoke Technical Instructions)Declaration of conformity(Electromotoric damper actuators GVD…)Environmental Declaration(Damper Actuator GAP GVD Environmental Product Description)Installation instruction(OpenAir GVD_GKD Series Electronic Damper Actuator for UL Listed Fire_Smoke and Smoke Control Dampers Installation Instructions) More Info

Overview

Details for GVD326.1U

The Siemens Building Technology GVD326.1U is a 230V SR 200# Fire & Smoke actuator, designed for use in industrial fire and smoke detection systems. Constructed with high-quality materials, this actuator provides reliable operation in demanding environments. Its compact size and easy installation make it a convenient solution for various applications. The GVD326.1U actuator is powered by 230V, delivering consistent performance and fast response times. It integrates seamlessly with Siemens fire and smoke detection systems, ensuring efficient and accurate detection in case of fire or smoke emergencies. With its precision engineering and advanced technology, the Siemens Building Technology GVD326.1U is an essential component for enhancing workplace safety and minimizing risks associated with fire and smoke hazards. At our HVAC supply store, we offer the best prices and fast shipping for the Siemens Building Technology GVD326.1U and a wide range of other industrial products. Contact us today to place your order and elevate your fire and smoke detection systems.

Specifications

Actuator Type: Electronic Fire and Smoke
Actuation Style: Rotary
Control or Fire/Smoke Type: Fire/Smoke Control Damper
Electronic Fusible Link (EFL): YES
Plenum or Standard Rating: Standard
Torque: 200 lb-in
Fail Safe: Yes
Spring return function: Spring return function
Control Signal: 2-position
Positioning time: Run time for 90° 30s nominal, Spring return 15 s max
Power consumption: 35 VA / 9 VA, Run / Hold
Ambient temperature, operation: 0…140 ºF
Ambient humidity, operation: 95 % r.h.
Angular rotation: 95°
Supply Voltage: 230 VAC
Frequency: 50/60
Auxiliary Switch: Yes
Auxiliary switch: 2
Cable length: 3 ft
Dimensions (W x H x D): 3.8 x 10.75 x 3.4 in
Material, housing: NEMA 1 / IP40, plenum-rated plastic, high temperature polymer
Standard: UL60730; cUL CSA 60730; CE conformity for Residential, Commercial, and Industrial environments
