G250B-N+NFX24-MFT-X1 | Globe Valve | 2" | 2 Way | 40 Cv | w/ Spring Return | 24V | MFT | Belimo

Globe Valve | 2" | 2 Way | 40 Cv | w/ Spring Return | 24V | MFT

Description

The Belimo G250B-N (G2 series) two-way threaded globe valve is designed for two-position, proportional, and floating control of hot & chilled water and steam applications in HVAC (heating, ventilation, and air conditioning) systems.

The G250B-N globe valves are excellent for fast opening/closing in applications with significant pressure drops. This mechanism is typically used in air handling units and fan coil units with heating or cooling coils.

Features

Two-way globe valve actuators from the G2 series provide:

• Modulating, floating, and two-position control signals for all sequences
• Visual stroke and position indicators
• Self-locking coupling
• Spring return mechanism
• ANSI Class 250 pressure rating (up to 400psi below 150 degrees Fahrenheit)
• Temperature resistance ranging from 20 to 280°F (from -7 to 138°C)

Benefits

• Durable construction (bronze housing and seat, stainless steel stem, and EPDM O-ring)
• Easy installation and fast system check
• High rangeability (100:1)
• Flexible piping
• Maintenance-free actuator (NFX24-MFT-X1)
