ZCP21M12 | Limit switch body, Limit switches XC Standard, ZCP, compact, 1NC+1 NO, snap action, M12 4P | Schneider Electric (Square D)

Schneider Electric (Square D) | ZCP21M12

The photo is for representation purposes only and may not be a photo of product being purchased.

Search products similar to ZCP21M12

Jump to: Documents Overview Specifications Reviews

Documents and manuals

Schneider Electric (Square D) ZCP21M12 Documents

More Info

Overview

Details for ZCP21M12

24VAC 4A Limit Switch ZCP21M12 by Schneider Electric (Square D) The ZCP21M12 limit switch by Schneider Electric (Square D) offers reliable and precise control in demanding industrial applications. This compact and robust switch features a 24VAC voltage rating and a 4A current capacity, making it suitable for various sensing and control tasks. Engineered with precision, the ZCP21M12 utilizes a snap-action mechanism for fast and dependable operation. Its rugged construction ensures durability in harsh environments. Additionally, this limit switch provides versatile mounting options for easy installation and integration into existing systems. The ZCP21M12 is designed to meet the needs of industrial engineers and maintenance professionals in a wide range of applications, including machinery control, conveyor systems, packaging equipment, and safety circuits. Trust Schneider Electric (Square D) for high-quality electrical components that enhance productivity and efficiency. Shop our HVAC supply store for the best deals on ZCP21M12 limit switches and enjoy fast shipping to keep your operations running smoothly. This ZCP body/contact assembly with connector has standard contacts and a plastic body. It has 1 x NO + 1 x NC snap action contacts and a M12 4-pin connector. It can be matched with any head, actuator or connector from the XCKD, XCKP and XCKT ranges.

Specifications

Range of Product: Telemecanique Limit switches XC Standard
Series name: Standard compact
Product or Component Type: Limit switch body
Device short name: ZCP
Design: Compact
Body type: Fixed
Associated head: ZCE63, ZCE06, ZCE21, ZCE24, ZCE09, ZCE29, ZCE67, ZCEH0, ZCE08, ZCE07, ZCE10, ZCEH2, ZCE62, ZCE02, ZCE11, ZCE05, ZCE14, ZCE64, ZCE28, ZCE01, ZCE66, ZCE13, ZCE65, ZCE27
Body Material: Plastic
Number of poles: 2
Contacts type and composition: 1 NC + 1 NO
Contact operation: Snap action
electrical connection: Male connector M12, 4 pins
Contacts insulation form: Zb
Contacts material: Silver plated contacts
Positive opening: With
Minimum actuation speed: 0.03 ft/s (0.01 m/s)
contact code designation: B300, AC-15 (Ue = 240 V), Ie = 1.5 A EN/IEC 60947-5-1 appendix A, R300, DC-13 (Ue = 250 V), Ie = 0.1 A EN/IEC 60947-5-1 appendix A
[Ui] rated insulation voltage: 300 VUL 508, 500 V 3)IEC 60947-1, 300 VCSA C22.2 No 14
maximum resistance across terminals: 25 mOhm IEC 60255-7 category 3
[Uimp] rated impulse withstand voltage: 6 kV IEC 60664, 6 kV IEC 60947-1
short-circuit protection: 10 A cartridge fuse gG
[Ie] rated operational current: 3 A 240 V, AC-15 EN/IEC 60947-5-1 appendix A, 0.27 A 250 V, DC-13 EN/IEC 60947-5-1 appendix A
[Ithe] conventional enclosed thermal current: 3 A
electrical durability: 5000000 cycles, DC-13 120 V, 4 W 60 cyc/mn 0.5 IEC 60947-5-1 appendix C, 5000000 cycles, DC-13 24 V, 10 W 60 cyc/mn 0.5 IEC 60947-5-1 appendix C, 5000000 cycles, DC-13 48 V, 7 W 60 cyc/mn 0.5 IEC 60947-5-1 appendix C
Width: 1.22 in (31 mm)
Height: 2.56 in (65 mm)
Depth: 1.18 in (30 mm)
Net Weight: 0.15 lb(US) (0.07 kg)
Product Compatibility: XCKP
ambient air temperature for operation: -13…158 °F (-25…70 °C)
Ambient Air Temperature for Storage: -40…158 °F (-40…70 °C)
Category: 22418-LIMIT SWITCH,IEC,XCKP&XCKT
Discount Schedule: T
GTIN: 3389110183962
Returnability: Yes
Country of origin: ID
Unit Type of Package 1: PCE
Number of Units in Package 1: 1
Package 1 Height: 1.30 in (3.3 cm)
Package 1 Width: 1.57 in (4 cm)
Package 1 Length: 3.82 in (9.7 cm)
Package 1 Weight: 2.43 oz (69 g)
Unit Type of Package 2: S02
Number of Units in Package 2: 77
Package 2 Height: 5.91 in (15 cm)
Package 2 Width: 11.81 in (30 cm)
Package 2 Length: 15.75 in (40 cm)
Package 2 Weight: 12.92 lb(US) (5.862 kg)
Warranty: 18 months
