8536SAG12V08 | Type S Full Voltage Starter, Size 00, NEMA 1 General Purpose, 208V 60Hz, 9A, 3-Poles, Non-Reversing | Schneider Electric (Square D)

208V 9A 3P NEMA1 Sz00 Starter The NCO-8536SAG12V08 from Schneider Electric (Square D) is a 208V 9A 3P NEMA1 Sz00 Starter. This starter is designed for use with motors that draw up to 9 amps and operate on 208 volts. It features a NEMA1 enclosure, which provides protection from dust and dirt, and a Sz00 size, which is the smallest size available. This starter is ideal for use in industrial applications where space is limited. Some of the key features of the NCO-8536SAG12V08 include: * 208V operation * 9A current rating * 3P operation * NEMA1 enclosure * Sz00 size * UL listed * CSA certified our HVAC supply store offers the best prices and fast shipping for your products! Type S NEMA motor starters are used for full voltage starting and stopping of AC squirrel cage motors. Type S motor starters have ratings up to 810 amperes. This 3 pole NEMA Size 00 non-reversing starter has an 9 ampere rating. This NEMA Size 00 motor starter has 3 phase ratings of 1.5 HP at 220 and 230 VAC and 2 HP at 460 and 575 VAC. This non-reversing NEMA motor starter has a melting alloy type overload relay that uses Type B thermal units to sense over current conditions. This NEMA starter has a 5 kA maximum SCCR (Short Circuit Current Rating) per UL508A when protected by an appropriate circuit breaker or fuse. Type S motor starters are available with replaceable coils in a wide variety of voltages. This starter has a 208 VAC 60 Hz operating coil wired for common control. A painted sheet steel NEMA 1 general purpose enclosure is used to protect this starter. Enclosure is 10.00 inches tall, 6.00 inches wide and 5.56 inches deep. A wide variety of accessories are available for Type S starters. Type S non-reversing NEMA motor starters are UL listed and CSA certified.
