EP050+LRX-E | Configurable | Electr. 2-way PI-CCV EPIV | AC/DC 24 V | BACnet MS/TP | Modbus RTU | MP-Bus | DN 1/2"[20] | Internal thread | GPM 6.6 | Belimo
The photo is for representation purposes only and may not be a photo of product being purchased.
Search products similar to EP050+LRX-E
Documents and manuals
Belimo EP050+LRX-E Documents
Overview
Details for EP050+LRX-E
Configurable | Electr. 2-way PI-CCV EPIV | AC/DC 24 V | BACnet MS/TP | Modbus RTU | MP-Bus | DN 1/2"[20] | Internal thread | GPM 6.6
Pressure Independent Valve, 2-way, Internal thread, (EPIV)Actuator specifications
Specifications
- Item Number
- EP050+LRX-E
- Brand
- Belimo
- Type
- EPIV
- Actuator Type
- Non fail-safe
- Control Type
-
- BACnet MS/TP
- Modbus RTU
- MP-Bus
- DC 2...10 V
- DC 0.5...10 V
- Hybrid (communicative / analog)
- Degree of Protection
- IP54, NEMA 2, UL Enclosure Type 2
- Electrical Connection
- cable
- Manual Override
- External push button
- Power Consumption (Holding)
- 1.3 W
- Power Consumption (Running)
- 3.5 W
- Running Time (Fail-safe)
- <35 s
- Running Time (Motor)
- 90 s
- Voltage AC/DC
- AC/DC 24 V
- Angle of Rotation
- 90
- End Fitting
- Internal thread
- Flow
- 6.6
- Fluid
- Chilled or hot water, up to 60% glycol max (open loop/steam not allowed)
- Pattern
- 2-way
- PI-Technology
- Electronic
- Pressure Independent
- YES
- Sensor Technology
- Ultrasonic with glycol and temperature compensation
- Trim
- Stainless steel
- Valve Size
- 0.5" [20]
