VFCII-143 | Flowmeter | range 2-20 GPM water. | Dwyer Instruments

The photo is for representation purposes only and may not be a photo of product being purchased.

Search products similar to VFCII-143

Jump to: Documents Overview Specifications Reviews

Documents and manuals

Dwyer Instruments VFCII-143 Documents

Instruction Manual Series VFC/VFCII Catalog Page More Info

Overview

Details for VFCII-143

Visualize Flow with Dwyer Instruments VFCII-143 Flowmeter The Dwyer Instruments VFCII-143 flowmeter offers a precise and reliable solution for measuring liquid flow rates ranging from 2 to 20 gallons per minute (GPM). Its Visi-Float design provides a clear visual indication of flow rate, eliminating the need for external power or calibration. Constructed from heavy-duty materials, this flowmeter ensures durability and longevity in industrial settings. Its acrylic body resists corrosion, while its stainless steel float and brass fittings provide excellent resistance to harsh chemicals and environmental conditions. The VFCII-143 flowmeter is versatile and can be easily installed in any orientation. It features a 1/2-inch male NPT connection and a maximum operating pressure of 150 PSI. Its compact design allows for space-saving installation in tight areas. Trust Dwyer Instruments for accurate and reliable flow measurement solutions. Choose the VFCII-143 flowmeter for efficient monitoring of liquid flow rates in industrial applications. Shop now at our HVAC supply store for the best prices and fast shipping.

Series VFC & VFCII Visi-Float® Acrylic Flowmeter

Used to Indicate Air or Water Flow, End Connections

The Series VFC Visi-Float® Flowmeter is a direct reading, precision machined, clear acrylic body flowmeter suitable for both gas and liquid applications. This Series consists of two 5" (127 mm) scale flowmeters, the VFC and VFC II. The VFC features PVC 1" female NPT connections and the VFC II units are equipped with acetal thermoplastic 1" male NPT fittings.

NIST CALIBRATION available in Product Configurator.

Product Applications

Medical equipment
Laboratory equipment
Air samplers
Gas analyzers
Pollution monitors
Chemical injectors
Cabinet purging
Remediation
Osmosis skids

Bodies are cut and precision machined from solid, clear acrylic blocks allowing for complete visual inspection
White background allows for better visibility of the float increasing reading accuracy
Direct reading scales are hot stamped into the plastic eliminating the need for troublesome conversions and increasing product operating life
Precision machined tapered bore enables high repeatability
Low installation costs with back or end connection options

Specifications

Series: VFC & VFCII Visi-Float® Acrylic Flowmeter
Category/Type: Flow
Type: Flowmeters
Series: VFC & VFCII Visi-Float® Acrylic Flowmeter
Service: Compatible gases and liquids.
Wetted Materials: Body: Acrylic plastic; O-ring: Buna-N (fluoroelastomer available);Metal parts: SS; Float: SS; Fittings: VFC: PVC; VFCII: Acetal thermoplastic.
Temperature & Pressure Limits: 100 psig (6.9 bar) @ 120°F (48°C);
Accuracy: 2% of FS.
Process Connection: VFC: 1" female NPT back connections. End connections optional. VFCII: 1" male NPT back connections. End connections optional.
Scale Length: 5" typical length.
Mounting Orientation: Mount in vertical position.
Weight: 24 to 25 oz (.68 to .71 kg).
Agency Approvals: Meets the technical requirements of EU Directive 2011/65/EU(RoHS II).
