VFC-141 | Flowmeter | range .5-5 GPM water. | Dwyer Instruments

The photo is for representation purposes only and may not be a photo of product being purchased.

Search products similar to VFC-141

Jump to: Documents Overview Specifications Reviews

Documents and manuals

Dwyer Instruments VFC-141 Documents

Instruction Manual Series VFC/VFCII Catalog Page More Info

Overview

Details for VFC-141

The Dwyer Instruments VFC-141 Water Flow Meter is a precise and dependable device designed for industrial applications. With a flow rate range of 0.5-5 GPM, it accurately measures the flow of water. Crafted by Dwyer Instruments, a trusted brand in the industry, this flow meter ensures reliable performance and durability. Its compact design makes it suitable for various environments, while its technical specifications meet the demands of industrial engineers and maintenance professionals. Key Features: - Measures water flow rate from 0.5 to 5 GPM - Compact design for easy integration - Durable construction for longevity - Can be calibrated for precise measurements - Provides accurate and reliable flow data Applications: - Industrial water monitoring systems - Laboratory testing and research - Water treatment plants - Irrigation systems - Chemical processing For the best prices and fast shipping on your Dwyer Instruments VFC-141 Water Flow Meter, choose our HVAC supply store. We prioritize customer satisfaction and provide exceptional support for all your industrial supply needs.

Series VFC & VFCII Visi-Float® Acrylic Flowmeter

Used to Indicate Air or Water Flow, End Connections

The Series VFC Visi-Float® Flowmeter is a direct reading, precision machined, clear acrylic body flowmeter suitable for both gas and liquid applications. This Series consists of two 5" (127 mm) scale flowmeters, the VFC and VFC II. The VFC features PVC 1" female NPT connections and the VFC II units are equipped with acetal thermoplastic 1" male NPT fittings.

NIST CALIBRATION available in Product Configurator.

Product Applications

Medical equipment
Laboratory equipment
Air samplers
Gas analyzers
Pollution monitors
Chemical injectors
Cabinet purging
Remediation
Osmosis skids

Bodies are cut and precision machined from solid, clear acrylic blocks allowing for complete visual inspection
White background allows for better visibility of the float increasing reading accuracy
Direct reading scales are hot stamped into the plastic eliminating the need for troublesome conversions and increasing product operating life
Precision machined tapered bore enables high repeatability
Low installation costs with back or end connection options

Specifications

Series: VFC & VFCII Visi-Float® Acrylic Flowmeter
Category/Type: Flow
Type: Flowmeters
Series: VFC & VFCII Visi-Float® Acrylic Flowmeter
Service: Compatible gases and liquids.
Wetted Materials: Body: Acrylic plastic; O-ring: Buna-N (fluoroelastomer available);Metal parts: SS; Float: SS; Fittings: VFC: PVC; VFCII: Acetal thermoplastic.
Temperature & Pressure Limits: 100 psig (6.9 bar) @ 120°F (48°C);
Accuracy: 2% of FS.
Process Connection: VFC: 1" female NPT back connections. End connections optional. VFCII: 1" male NPT back connections. End connections optional.
Scale Length: 5" typical length.
Mounting Orientation: Mount in vertical position.
Weight: 24 to 25 oz (.68 to .71 kg).
Agency Approvals: Meets the technical requirements of EU Directive 2011/65/EU(RoHS II).
