TRI-200-50 | Tridicator gage | range 0-200 psi (0-1400 kPa) | 1/2" NPT CBM. | Dwyer Instruments

The photo is for representation purposes only and may not be a photo of product being purchased.

Search products similar to TRI-200-50

Jump to: Documents Overview Specifications Reviews

Documents and manuals

Dwyer Instruments TRI-200-50 Documents

Series TRI Catalog Page More Info

Overview

Details for TRI-200-50

Dwyer Instruments TRI-200-50: Precision Measurement for Pressure MonitoringThe Dwyer Instruments TRI-200-50 is a 1/2" NPT CBM with a pressure range of 0-200 PSI and a temperature range of 80-290. This high-accuracy pressure gauge is designed to provide reliable and precise pressure readings in various industrial applications. With its rugged construction and durable materials, this gauge ensures long-lasting performance in demanding environments. Its compact size and lightweight design make it easy to install and use. The clear dial allows for quick and accurate readings, while the high-contrast markings enhance visibility. The TRI-200-50 is suitable for monitoring pressure in hydraulic systems, process lines, and other industrial equipment. Shop our HVAC supply store now for the best prices and fast shipping on your Dwyer Instruments TRI-200-50 pressure gauge!

SERIES TRI TRIDICATOR GAGE

Combination Pressure/Temperature Gage

The Series TRI combines the value of an individual pressure gage and thermometer in one instrument. These tridicators simplify installation which reduces time and saves money. The movable dial with blue pressure markings and red temperature markings make the instrument easy to read. Pressure is indicated in both psi and kPa, while temperature is measured in both Fahrenheit and Celsius. Series TRI comes in three different connection options including lower mount, center back mount, and center back mount with extension shank.

California Residents: Click Here for Proposition 65 WARNING.

Product Applications

Boiler Monitoring

Specifications

Series: TRI TRIDICATOR GAGE
Category/Type: Pressure
Type: Single Pressure
Series: TRI TRIDICATOR GAGE
Service: Compatible gases and liquids.
Wetted Materials: Brass connection and phosphor bronze Bourdon tube.
Housing: Drawn Steel; black finish.
Accuracy: Pressure ±3-2-3%; Temperature ±1 scale division.
Temperature Range: All models: 80 to 290°F (30 to 140°C).
Temperature Limits: Ambient: -40 to 250°F (-40 to 120°C); Process: 80 to 290°F (30 to 140°C).
Pressure Limits: Full scale range.
Size: 3" (76 mm)
Process Connections: 1/2" male NPT back or bottom; 1/4" male NPT back connection.
Weight: 12.3 oz (348.7 g).
