QFA4160D | Outside Air RH and Temp Sensor, 2 percent certified, RH: 0-10 Vdc, T: 0-10 Vdc | Siemens Building Technology

The photo is for representation purposes only and may not be a photo of product being purchased.

Search products similar to QFA4160D

Jump to: Documents Overview Specifications Reviews

Documents and manuals

Siemens Building Technology QFA4160D Documents

Datasheet(Room_sensor QFA41..)Datasheet(QFA3100_4100 Series RH Sensors for Critical Environments or Outdoor Use Technical Specification Sheet)Declaration of conformity(EU Declaration of Conformity QFA41xx/AQF41xx)Declaration of conformity(RCM Supplier's Declaration QPA../QPM../QFA..)Declaration of conformity(UK Declaration of conformity for QFA41xx/AQF41xx)Declaration of conformity(Test report MTBF for QFM... QFA..)Environmental Declaration(Room sensor for relative humidity and temperature) More Info

Overview

Details for QFA4160D

Siemens Building Technology QFA4160D Control System: Precision Humidity Control The Siemens Building Technology QFA4160D is an advanced control system specifically designed for maintaining precise humidity levels in commercial and industrial environments. With its ability to monitor and adjust humidity within a range of 2% to 98%, it ensures optimal conditions for sensitive equipment and processes. The QFA4160D features a user-friendly digital display for easy setup and operation. It allows for customizable setpoints and alarm thresholds, enabling tailored control to meet specific requirements. Additionally, its compact design and wall-mount capability provide flexible installation options. This humidity control system is ideal for applications such as data centers, cleanrooms, laboratories, and manufacturing facilities where precise humidity levels are crucial for maintaining equipment performance and product quality. Shop now at Our HVAC supply store for the best prices and fast shipping on your QFA4160D control system!

Specifications

Measurement range humidity: 0…100 % r.h.
Measuring range, temperature: 0…50 °C, -35…35 °C, -40…70 °C
Time constant: Humidity: 20 s, Temperature: 510 s
Signal output humidity: DC 0...10 V
Signal output temperature: DC 0...10 V
Operating voltage: 24 VAC, 13.5…35 VDC
Analog outputs: 0-10 V
Measuring range: Temperature: -40 to 158°F; Humidity: 0 to 100% RH
Measurement accuracy: At 15…35 °C: ±0.6 K, 23 % r.h., 0…100 % r.h.: ±2 % r.h.
Communication: Includes 3-point calibration certificate
Display: LCD
Dimensions (W x H x D): 80 x 144 x 39 mm
