PAX25-150 | PAX EXPANSION TANK 25L (6.6GAL) 150PSI | Taco

The photo is for representation purposes only and may not be a photo of product being purchased.

Search products similar to PAX25-150

Jump to: Documents Overview Specifications Reviews

Documents and manuals

Taco PAX25-150 Documents

Datasheet Installation Instructions More Info

Overview

Details for PAX25-150

NCO PAX25-150-Taco 6.6GAL 150PSI Expansion Tank The NCO PAX25-150-Taco expansion tank is a critical component for maintaining pressure stability and system efficiency in hydronic heating and cooling systems. Manufactured by Taco, a trusted leader in the industry, this expansion tank features a robust 6.6-gallon capacity and a maximum pressure rating of 150PSI. Its primary function is to absorb excess pressure caused by thermal expansion, preventing potential damage to system components and ensuring optimal system performance. The NCO PAX25-150-Taco is ideal for commercial and industrial applications, such as large-scale HVAC systems, district heating networks, and industrial process cooling systems. It is engineered to withstand the rigors of demanding operating environments and is designed to provide years of reliable service. Technical Specifications: * Capacity: 6.6 gallons * Maximum Pressure: 150PSI * Brand: Taco * Model Number: PAX25-150 * Dimensions: [Add dimensions if available] * Weight: [Add weight if available] Our HVAC supply store is your trusted source for NCO PAX25-150-Taco expansion tanks and a wide range of other industrial supplies. We offer competitive pricing, fast shipping, and exceptional customer service. Contact us today to learn more about our products and services.

For Permanent Separation of Air and Water

Taco PAX Series Potable Water Expansion Tanks are bladder type tanks that provide permanent separation of air and water and designed for use in potable water systems. All wetted components are built of FDA approved materials and can be offered with NSF/ANSI 61-G Certification and Listing as an option. Taco PAX model expansion tanks feature a heavy-duty Butyl rubber bladder for long lasting performance.

PAX Series Potable Water Expansion Tanks are designed, constructed and tested to ASME Section VIII, Div. 1 requirements. Computerized product selection helps you choose the Expansion Tank that is just the right fit for your application requirements. All fabrication is done in-house to assure a high level of quality.

Performance Data

Capacity: 2.6-132 Gallons (10-500 Liters)
Diameters: 12-24″
Height: 12-85″
Working Pressure: 150 PSI, (Optional 175, 250)
Max. Operating Temp.: 240°F

Features

Designed, constructed and tested to ASME Section VIII, Div. 1 requirements.
SS System Connection
Heavy Duty butyl rubber bladder
Partial Acceptance bladder design (field replaceable)
All fabrication done in house
Computerized selections to ensure fast and easy design
National Board Registration
CRN registration (optional)
NSF/ANSI 61-G Certified and Listed (Optional)

Applications

Potable Water Systems
Closed Loop Chilled and Hot Water
