NYL2-C041/DS24-180 | 2 Way Butterfly Valve | 4 Inch | 24 VAC / VDC Spring Return Actuator | Bray Commercial

The photo is for representation purposes only and may not be a photo of product being purchased.

Search products similar to NYL2-C041/DS24-180

Jump to: Documents Overview Specifications Reviews

Documents and manuals

Bray Commercial NYL2-C041/DS24-180 Documents

Bray NYL2-C041/DS24-180 Catalog Bray NYL2-C041/DS24-180 Submittal Bray NYL2-C041/DS24-180 Installer's Guide Bray NYL2-C041/DS24-180 Specifications Bray DS24-180 Submittal Bray DS24-180 Installer's Guide

Overview

Details for NYL2-C041/DS24-180

NYL2-C041/DS24-180: 4" Butterfly Valve with Lug and 50 PSI Pressure Rating Engineered by Bray Commercial, the NYL2-C041/DS24-180 is a highly reliable 4-inch butterfly valve designed to provide precise flow control in demanding industrial applications. This valve features a rugged lug-style body for secure installation and enhanced durability. With a pressure rating of 50 PSI, the NYL2-C041/DS24-180 is suitable for handling a wide range of liquids and gases. Its butterfly disc design ensures quick and efficient flow regulation, making it ideal for applications where precise flow control is critical. Constructed from premium materials, this valve exhibits excellent corrosion resistance and wear resistance, ensuring long-lasting performance even in harsh operating environments. Its compact design allows for easy integration into existing piping systems, saving space and reducing installation time. Our HVAC supply store is proud to offer the NYL2-C041/DS24-180 butterfly valve at competitive prices. Order now and experience the exceptional quality and reliability of Bray Commercial products.

Description:

Bray NYL2-C041/DS24-180 2 Way Butterfly Valve, 4 Inch, 24 VAC / VDC Spring Return Actuator.

Bray NY and AB series butterfly valves have been replaced by the all new 3L series located here:

Resilient seated butterfly valve model NYL2-C041 features:
- 4 inch.
- 100 mm.

- 50 PSI close-off.

- 90 degree 841 Cv.
- 60 degree 274 Cv.
- 2-way flow.

- Normally closed.

- For use with hot water, chilled water, condenser water, up to 50% glycol solutions.

- Cast iron body.

- Nylon coated ductile iron disc with optional aluminum bronze disc.

- EPDM peroxide cured seat.

- 416 stainless steel stem.

Factory installed actuator model DS24-180 features:
- Spring return.
- 24 VAC or 24 VDC.
- On/Off.

- Electric stall detection.

- 3/8 inch conduit connection.

- Standard cable.

- Hex head screw manual override.

- Standard NEMA 2, IP54 enclosure.

- Optional auxiliary switch available.

Bray’s NY and AB series commercial resilient seated butterfly valves set the design standard for quality, reliability and long life in a wide variety of HVAC applications. Specifically designed for automated applications on chilled water, hot water and condenser water, all NY and AB series automated butterfly valves are 100% factory tested for bubble-tight shutoff and low seating/unseating torque.

NY, AB and SS Series valves are available in 2-way configurations to 30" and 3-way configurations to 20”. Actuators include industrial electric, commercial electric, high pressure pneumatic and low pressure pneumatic in both spring return and non spring return variations for on/off and modulating control applications. Differential pressure ratings are available for high close-off (up to 175 PSI) and low close-off (50 PSI) requirements.

Actuator Power:24V
Flow:2 Way
Return Position:Spring Return
Valve Size (In.):4
