NYL2-C025/DS24-180 | 2 Way Butterfly Valve | 2.5 Inch | 24 VAC / VDC Spring Return Actuator | Bray Commercial

The photo is for representation purposes only and may not be a photo of product being purchased.

Search products similar to NYL2-C025/DS24-180

Jump to: Documents Overview Specifications Reviews

Documents and manuals

Bray Commercial NYL2-C025/DS24-180 Documents

Bray NYL2-C025/DS24-180 Catalog Bray NYL2-C025/DS24-180 Submittal Bray NYL2-C025/DS24-180 Installer's Guide Bray NYL2-C025/DS24-180 Specifications Bray DS24-180 Submittal Bray DS24-180 Installer's Guide

Overview

Details for NYL2-C025/DS24-180

Bray Commercial NYL2-C025/DS24-180 LUG Valve: BFA 2.5" 175# LUG 24VAC S/R Bray Commercial's BFA 2.5" 175# LUG 24VAC S/R valve is engineered to deliver exceptional performance and reliability in demanding industrial applications. This valve features a robust construction with a 2.5-inch LUG design for increased durability and resistance to harsh environments. Its 175# pressure rating ensures safe and efficient operation in high-pressure systems. The 24VAC solenoid actuator provides precise and reliable control, making it ideal for use in applications requiring remote operation or automated processes. The valve's S/R (single-seated, resilient) design offers excellent sealing capabilities, minimizing leakage and ensuring long-lasting performance. Whether you need to control flow in hydraulic systems, pumps, or other industrial equipment, Bray Commercial's NYL2-C025/DS24-180 LUG valve is an excellent choice. Its combination of durability, precision, and efficiency makes it a valuable asset for demanding industrial applications. Shop now at our HVAC supply store for the best prices and fast shipping!

Description:

Bray NYL2-C025/DS24-180 2 Way Butterfly Valve, 2.5 Inch, 24 VAC / VDC Spring Return Actuator.

Bray NY and AB series butterfly valves have been replaced by the all new 3L series located here:

Resilient seated butterfly valve model NYL2-C025 features:
- 2-1/2 inch.
- 65 mm.

- 175 PSI close-off.

- 90 degree 282 Cv.
- 60 degree 107 Cv.
- 2-way flow.

- Normally closed.

- For use with hot water, chilled water, condenser water, up to 50% glycol solutions.

- Cast iron body.

- Nylon coated ductile iron disc with optional aluminum bronze disc.

- EPDM peroxide cured seat.

- 416 stainless steel stem.

Factory installed actuator model DS24-180 features:
- Spring return.
- 24 VAC or 24 VDC.
- On/Off.

- Electric stall detection.

- 3/8 inch conduit connection.

- Standard cable.

- Hex head screw manual override.

- Standard NEMA 2, IP54 enclosure.

- Optional auxiliary switch available.

Bray’s NY and AB series commercial resilient seated butterfly valves set the design standard for quality, reliability and long life in a wide variety of HVAC applications. Specifically designed for automated applications on chilled water, hot water and condenser water, all NY and AB series automated butterfly valves are 100% factory tested for bubble-tight shutoff and low seating/unseating torque.

NY, AB and SS Series valves are available in 2-way configurations to 30" and 3-way configurations to 20”. Actuators include industrial electric, commercial electric, high pressure pneumatic and low pressure pneumatic in both spring return and non spring return variations for on/off and modulating control applications. Differential pressure ratings are available for high close-off (up to 175 PSI) and low close-off (50 PSI) requirements.

Actuator Power:24V
Flow:2 Way
Return Position:Spring Return
Valve Size (In.):2.5
