L1121-B6SI1-FHAN | Circulator Pump | Stainless Steel | 1/8 HP | 230V | Single Phase | 0.73A | 3250 RPM | Flanged | 250 PSI Max Press. | Integral Flow Check | Series LoadMatch | Taco

The photo is for representation purposes only and may not be a photo of product being purchased.

Search products similar to L1121-B6SI1-FHAN

Jump to: Documents Overview Specifications Reviews

Documents and manuals

Taco L1121-B6SI1-FHAN Documents

Datasheet Replacement Parts Installation Instructions More Info

Overview

Details for L1121-B6SI1-FHAN

1/8HP Taco 208/230V 3250RPM Circulator (L1121-B6SI1-FHAN) Taco's L1121-B6SI1-FHAN circulator is a 1/8HP, 208/230V, 3250RPM circulator designed for industrial and commercial applications. It features a bronze body, cast iron impeller, and mechanical seal for durability and long life. The L1121-B6SI1-FHAN is ideal for circulating hot or cold water in hydronic systems, such as radiant floor heating systems and domestic hot water systems. Key Features: - 1/8HP motor for powerful circulation - 208/230V operation for compatibility with most electrical systems - 3250RPM speed for efficient circulation - Bronze body for corrosion resistance - Cast iron impeller for durability - Mechanical seal for long life Benefits: - Circulates hot or cold water efficiently in hydronic systems - Ideal for radiant floor heating systems and domestic hot water systems - Durable construction for long-lasting performance - Easy to install and maintain Applications: - Hydronic heating systems - Radiant floor heating systems - Domestic hot water systems - Industrial and commercial applications Shop our HVAC supply store today for the best prices and fast shipping on Taco circulators and other industrial and commercial products!

LoadMatch Circulators

Taco LoadMatch ^® Circulators are designed for quiet, efficient operation on LoadMatch ^® Fan Coil Heating and Cooling Systems. Each circulator includes a removable Integral Flow Check (IFC ^®) to prevent gravity flow and reduce installation costs. An anti-condensate baffle prevents the build up of condensate on the motor windings when pumping chilled water. The unique, field serviceable cartridge contains all moving parts. Replacing the cartridge rebuilds the circulator. With no mechanical seal, the self-lubricating, maintenance-free design of the LoadMatch ^® Circulators provides unmatched reliability.

Performance Data

Min. Fluid Temp.: 32º F (0º C)
Max. Fluid Temp. Cast Iron or Stainless Steel: 230º F (110º C)
Max. Fluid Temp. Bronze: 220º F (104º C)
Max. Working Pressure: 200 PSI
Available in 115V, 230V or 277V voltages
Optional 0-10V variable speed control
Connection Sizes: 3/4″, 1″, 1-1/4″, 1-1/2″ Flanged, 3/4″ Sweat

Features

Integral Flow Check (IFC)–Eliminates In-Line Flow Check, Reduces Installed Cost, Easy to Service
Improved Performance vs. In-Line Flow Checks
Exclusive Anti-Condensate Baffle (ACB)—Protects motor windings against condensate build-up in chilled water systems
Unique Replaceable Cartridge Design—Field Serviceable
Unmatched Reliability—Maintenance Free
Quiet, Efficient Operation
Direct Drive – Low Power Consumption
Standard High Capacity Output
Compact Design
Self Lubricating
No Mechanical Seal

Applications

LoadMatch^® Fan Coil Heating and Cooling Systems
