HD-3608-BM | Rectangular 36 x 08 Zone Damper-BM | iO HVAC Controls

Rectangular 36x8 Zone Damper: iO HD-3608-BM The iO HVAC Controls HD-3608-BM (SKU: HD-3608-BM) is a robust and high-performance rectangular zone damper engineered for efficient air distribution and control in HVAC systems. Its precision-crafted construction and advanced features provide enhanced airflow management, energy savings, and reliable operation. Technical Specifications: * Dimensions: 36" x 8" * Blade Material: Galvanized steel * Frame Material: Aluminum * Number of Blades: 10 * Blade Profile: Aerodynamically designed for optimal airflow * Actuator: 24 VAC/DC, 2-position, spring return (not included) Features and Benefits: * Precise airflow control for optimal indoor air quality and comfort * Low-leakage design minimizes energy loss and improves system efficiency * Corrosion-resistant materials ensure durability and long service life * Aerodynamic blade design reduces pressure drop and noise levels * Compatible with most actuator systems for flexible control options Applications: * Air handling units * VAV systems * Exhaust systems * Industrial ventilation * Commercial and residential HVAC systems Maximize airflow efficiency and reduce energy consumption in your HVAC system with the iO HVAC Controls HD-3608-BM Rectangular 36x8 Zone Damper. Order now from our HVAC supply store for the best prices and fast shipping!

Description

The HD Series dampers are extruded aluminum parallel blade dampers with a 24 volt spring return actuator. These dampers are shipped complete and ready for installation. The HD Series dampers can be installed in any position. They are rated for duct systems with less than 1.0” WC. The damper has a simple adjustment for setting the minimum position.

Features and Benefits:

• Compatible with most zone control panels
• Extruded aluminum
• 24 volt synchronous motor
• Quiet operation
• Simple adjustment for setting the minimum position

Warranty: 5 years

Specifications

Construction Extruded aluminum
Sizes 6” x 6” to 36” x 24” side-mount or bottom-mount motor
Damper Actuator Type 24VAC, 10VA, two-wire power close/spring open
