GVD121.1U | Damper Actuator | Spring Return | 24 VAC | On/Off | 200 lb-in | Siemens Building Technology
The photo is for representation purposes only and may not be a photo of product being purchased.
Search products similar to GVD121.1U
Documents and manuals
Siemens Building Technology GVD121.1U Documents
Datasheet(OpenAir GVD/GKD Electronic Damper Actuator US Listed Fire/Smoke Technical Instructions)Declaration of conformity(Electromotoric damper actuators GVD…)Environmental Declaration(Damper Actuator GAP GVD Environmental Product Description)Installation instruction(OpenAir GVD_GKD Series Electronic Damper Actuator for UL Listed Fire_Smoke and Smoke Control Dampers Installation Instructions) More Info
Overview
Details for GVD121.1U
Siemens GVD121.1U: Precision Power for Demanding Applications
The Siemens GVD121.1U is a high-performance 2-point position indicating switch designed to enhance control and monitoring operations in industrial settings. With its robust construction and advanced features, this switch delivers reliable and precise performance in demanding applications.
Key Features:
* Rotary actuator offers smooth and tactile switching action
* Internal spring mechanism provides stable contact pressure for accurate switching
* Versatile terminal connections for easy wiring and integration
* IP65 enclosure rating ensures protection against dust and water ingress
* Compact design allows for installation in confined spaces
Applications:
* Control and monitoring of industrial machinery
* Position sensing for automated systems
* Limit switches for safety and automation
* Process control and automation systems in industrial environments
Benefits:
* Enhanced control and monitoring capabilities for increased operational efficiency
* Reliable performance even in harsh industrial conditions
* Reduced maintenance and downtime due to robust construction
* Flexible installation options for various industrial applications
Trust Siemens GVD121.1U for exceptional precision and reliability in your critical industrial operations. Our HVAC supply store offers competitive pricing and fast shipping to meet your project needs. Contact us today to learn more about this advanced position indicating switch.
Specifications
- Actuator Type
- Electronic Fire and Smoke
- Actuation Style
- Rotary
- Control or Fire/Smoke Type
- Fire/Smoke Control Damper
- Electronic Fusible Link (EFL)
- YES
- Plenum or Standard Rating
- Standard
- Torque
- 200 lb-in
- Fail Safe
- Yes
- Spring return function
- Spring return function
- Control Signal
- 2-position
- Positioning time
- Run time for 90° 30s nominal, Spring return 15 s max
- Power consumption
- 35 VA / 9 VA, Run / Hold
- Ambient temperature, operation
- 0…140 ºF
- Ambient humidity, operation
- 95 % r.h.
- Angular rotation
- 95°
- Supply Voltage
- 24 VAC
- Frequency
- 50/60
- Auxiliary switch
- 0
- Cable length
- 3 ft
- Dimensions (W x H x D)
- 3.8 x 10.75 x 3.4 in
- Material, housing
- NEMA 1 / IP40, plenum-rated plastic, high temperature polymer
- Standard
- UL60730; cUL CSA 60730; CE conformity for Residential, Commercial, and Industrial environments
