F7-HSS | Horizontal mount level switch | 316SS float and stem | temperature limit 392°F (200°C) | pressure limit 300 psig (20.7 bar) | 1/2" NPT (int/ext) mounting | Dwyer Instruments

The Series F6 & F7 Horizontal Float Level Switches are designed to mount through the walls of tanks and other vessels. Internally mounted models F6-HPS-11, F6-MHS and F7-SS6 are secured to the wall of the tank or vessel from the inside while model F6-HPS-21 is mounted from the outside (externally). Models F7-HSS and F6-MHS2 can be installed internally or externally.

The Series F6 & F7 Specialty Float Level Switches are designed for unique applications. Model F7-SS5B/BNC can be used with viscous liquids or liquids with suspended metal particles. Use model F7-LL for low level detection (≥ 5/8"). The non-intrusive bottle style F7-EB mounts completely outside the tank at the actuation level. Suspend model F7-WBB in stand pipes or sumps for leak detection or drop into wells for ground-water monitoring.

California Residents:  Click Here for Proposition 65 WARNING.

Product Applications

• Water level monitoring
• Oil level control
• Chemical level indication
• Sumps
• Stand pipes
• Tank level control
