DPG-205 | Digital pressure gage | selectable engineering units: 100.0 psig | 7.03 kg/cm² | 6.895 bar | 203.6" Hg | 230.7 ft w.c. | 224.8 ft seawater @ 4°C | 689.5 kPa | 1600 oz/in² | 2768" w.c. | 6895 mbar | 7031 cm w.c. | 5172 mm Hg. | Dwyer Instruments

The photo is for representation purposes only and may not be a photo of product being purchased.

Search products similar to DPG-205

Jump to: Documents Overview Specifications Reviews

Documents and manuals

Dwyer Instruments DPG-205 Documents

Instruction Manual Series DPG-200 Catalog Page More Info

Overview

Details for DPG-205

Dwyer Instruments DPG-205: NEMA4A Digital Pressure Gauge with Transmitter The DPG-205 from Dwyer Instruments is a NEMA4A-rated digital pressure gauge with a built-in transmitter for remote monitoring. It features a rugged construction with a 316L stainless steel diaphragm for durability and corrosion resistance. The high-accuracy sensor provides precise pressure measurements, ideal for industrial applications. Key Features: - NEMA4A rating ensures protection against dust and water ingress - 316L stainless steel diaphragm for corrosion resistance - Built-in transmitter for remote monitoring - High-accuracy sensor for precise measurements - Digital display for easy readability - Suitable for harsh industrial environments The DPG-205 is widely used in various industries, including chemical processing, power generation, oil and gas, and manufacturing. Its durability and precision make it a reliable choice for engineers and maintenance professionals who need accurate pressure monitoring and control. Our HVAC supply store offers the DPG-205 at the best prices with fast shipping. Contact us today for more information and to place your order!

SERIES DPG-200 DIGITAL PRESSURE GAGE

3-in-1: Gage, Transmitter and Switch

The Series DPG-200 Digital Pressure Gage has a precise ±0.25% full scale accuracy. The 4 digit digital display will reduce the potential for errors in readings by eliminating parallax error commonly produced with analog gages. The DPG-200 is packaged in a durable extruded aluminum case designed to meet NEMA 4X (IP66). The unit is powered by 12-24 VDC/VAC and contains two alarm set points along with a 4-20 mA process output. A four-button keypad allows easy access to features. These features include backlight, peak and valley, auto zero and conversion of the pressure units.

NIST CALIBRATION available in Product Configurator.

Product Applications

Process control
Compressor control

High accuracy provides exceptional measurement minimizing costly out ofspecification conditions
Backlit 4-digit display provides clear parallax-free reading reducing potential forerrors
Durable aluminum case to meet NEMA 4X (IP66) requirements supports use inharsh or outdoor environments
Push-button zero reduce installation and service time

Specifications

Series: DPG-200 DIGITAL PRESSURE GAGE
Category/Type: Pressure
Type: Single Pressure
Series: DPG-200 DIGITAL PRESSURE GAGE
: DIGITAL GAGE SPECIFICATIONS
Service: Liquids and non-combustible compatible gases.
Wetted Materials: Type 316L SS.
Housing: Black polycarbonate front & back cover; anodized aluminum extruded housing with recessed grooves; polycarbonate overlay; Buna-N O-rings; 316L SS sensor construction.
Accuracy: 0.25% F.S. ±1 least significant digit. (Includes linearity; hysteresis; repeatability).
Pressure Limit: 2x pressure range for models 1000 psi; 5000 psi for 3000 psi range; 7500 psi for 5000 psi range.
Temperature Limits: 32 to 158°F (0 to 70°C).
Process Connection: 1/4" male NPT.
Display: 4 digit (.425" H x .234" W digits).
Size: 3.00" OD x 1.90" deep (not including cables).
Weight: 8.84 oz (275 g).
: SWITCH SPECIFICATIONS
Switch Type: 2 SPDT Form C contacts.
Electrical Rating: 0.5 A @ 125 VAC resistive; 1 A @ 24 VDC.
Relay Differential: 1 least significant digit.
Electrical Connections: 3 ft (.91 m) cable.
Mounting Orientation: Mount in any position.
Set Point Adjustment: Via menu.
: TRANSMITTER SPECIFICATIONS
Temperature Limits: 0 to 158°F (0 to 70°C).
Thermal Effect: Between 70 to 158°F = 0.016%/°F. Between 0 to 70°F = 0.026%/°F.
Power Requirements: 12-24 VAC +/- 20% 50-400 Hz; 12-24 VDC +/-20%.
Output Signal: 4-20 mA.
Loop Resistance: 600 ohms maximum.
Power Consumption: 0.8 W max.
Electrical Connections: 3 ft (.91 m) cable.
Enclosure Rating: Designed to meet NEMA 4X (IP66).
