APT-40-1SN | AC power transformer | 120 VAC input | 24 VAC isolated output | 40 VA | single hub | Dwyer Instruments

The photo is for representation purposes only and may not be a photo of product being purchased.

Search products similar to APT-40-1SN

Jump to: Documents Overview Specifications Reviews

Documents and manuals

Dwyer Instruments APT-40-1SN Documents

Series APT Catalog Page More Info

Overview

Details for APT-40-1SN

APT-40-1SN 120V-24V 40VA FtMntXfrmrW/1Hub by Dwyer Instruments Dwyer Instruments' APT-40-1SN is a step-down transformer designed to convert 120V AC power to 24V AC power. It's ideal for powering low-voltage devices in industrial settings. With a 40VA capacity, it can handle loads up to 40 watts. The foot-mounted design allows for easy installation and provides stability. The transformer features a single hub for connecting multiple devices. This transformer is constructed using high-quality materials for durability and reliability. Its compact size makes it suitable for use in tight spaces. It's a versatile solution for powering various devices, including sensors, controllers, and other electrical equipment. Shop now at our HVAC supply store for the best prices and fast shipping on all your industrial supply needs!

SERIES APT AC POWER TRANSFORMERS

40 VA to 150 VA, Single or Dual Hub, Circuit Breaker, UL Class 2

The SERIES APT AC Power Transformers provide isolated step-down to 24 VAC with models offering VA ratings of 20, 40, 50, 75, 96, or 150 VA’s. These cost efficient transformers are offered in single or dual 1/2" NPT threaded hub mounts with 8-1/2" 18 AWG wire leads, to meet the installation requirements of a variety of building automation and control panel applications in HVAC. All models are UL Class 2 listed.

Product Applications

BAS
HVAC

Single or dual 1/2" NPT
Universal supply voltage input
With or without integral circuit breaker

Specifications

Series: APT AC POWER TRANSFORMERS
Category/Type: Process Control
Type: Power Supplies and Transformers
Series: APT AC POWER TRANSFORMERS
Input Voltage: See model chart on catalog page.
Input Frequency: 50/60 Hz.
Output Voltage: See model chart on catalog page.
Output VA Rating: 20; 40; 50; 75; 96; or 150 VA.
Mounting: Slotted foot mount with single; or dual 1/2" NPT hub.
Current Protection: See model chart on catalog page.
Electrical Connections: Models ending in -20: 20" (508 mm) 18 AWG leads; Allother models: 8.5" (210 mm) 18 AWG leads.
Weight: See model chart on catalog page.
Agency Approvals: CE; cULus.
