ACUF-150-AC-2 | 1-1/2" Sweat ACCU-FLO Balancing Valve | Taco

1.5"Swt AccuFlo Circuit Setter [ACUF-150-AC-2] by Taco The Taco ACUF-150-AC-2 is a 1.5" sweat AccuFlo circuit setter designed for use in hydronic heating and cooling systems. It features a lead-free bronze body, a stainless steel piston, and a Buna-N O-ring for durability and corrosion resistance. The ACUF-150-AC-2 has a maximum working pressure of 150 psi and a temperature range of 20°F to 250°F, making it suitable for a wide range of applications. The Taco ACUF-150-AC-2 is easy to install and service, with a captive packing nut that eliminates the need for a backup wrench. It also features a built-in bubble view port for easy system bleeding. The ACUF-150-AC-2 is a reliable and efficient circuit setter that will help to ensure optimal system performance. Shop now at our HVAC supply store for the best prices and fast shipping on Taco products!

With Taco Accu-Flo Balancing Valves, you will experience greater balancing accuracy than ever before. Most conventional balancing valves use a variable orifice that delivers poor balancing accuracy, high pressure drops, low regains, and an inability to read low flows. The Taco Accu-Flo Balancing Valves use a modified venturi design, instead, to deliver four to five times greater accuracy. Flow Measurement is independent of stem and ball position, and the tamper-resistant memory stop provides accurate resetting. With calibrated nameplate for presetting, all-brass interior parts, precision machining and 100% factory testing, these valves are the highest quality fixed-port venturi balancing valve on the market today.

Performance Data

Features

The Taco Accu-Flo combines superior engineering and design, precision machining and 100% factory testing to ensure the highest quality fixed port venturi balancing valve on the market today. Accuracy of the Taco Accu-Flo is 4-5 times greater than variable orifce balancing valves.

Features:

Accuracy 4-5 times greater than variable orifice balancing valves.

Flow measurement independent of stem and ball position.

Ability to read nameplate setting not required to determine flow.

Tamper resistant memory stop for accurate resetting.

Positive shut-off.

Ability to read low flows.
