112105 | 1" NPT Enhanced Air Separator | Xylem-Bell & Gossett

Xylem-Bell & Gossett EAS-1 Enhanced Air Separator (112105): The Xylem-Bell & Gossett EAS-1 is a highly efficient air separator designed to remove entrained air from hydronic systems. This 1" separator features a unique internal design that promotes the coalescing and release of air bubbles, reducing system noise and improving pump performance. Its compact size and easy installation make it suitable for a wide range of applications, including HVAC systems, boilers, and chillers. Key Features: * Removes entrained air from hydronic systems * Improves pump efficiency and reduces noise * Compact design for easy installation * Durable construction for long-lasting operation Technical Specifications: * Size: 1" * Maximum Pressure: 125 psi * Maximum Temperature: 250°F Applications: * HVAC systems * Boilers * Chillers * Hydronic systems requiring air removal Shop our HVAC supply store for the best prices and fast shipping on your Xylem-Bell & Gossett products! See how Enhanced Air Separator works: as system fluid enters through the inlet, (either straight or angle) the diffuser distributes flow evenly across the stainless steel, wire brush-like medium. Air bubbles, even micro air bubbles, stick to the brush filaments. Trapped air rises above the diffuser through a baffle where the air is then released through an opening at the top. De-aerated water then goes back into the system.
EAS is very easy and convenient to install:
-Requires no minimum pipe run.
-Straight or angle pattern installation capability.
-Usable for systems with either steel compression or diaphragm expansion tanks.
-Removable and replaceable +" high capacity vent.
EAS is built to last:
-Rugged two-piece cast iron body and cap construction.
-Internal parts are all stainless steel.
-Vent has a brass body and non-ferrous internals.
Body Type: Cast Iron
Connection Type: Threaded
