1F85U-22NP | 80 Series Thermostat | Universal Multi Stage | WHITE-RODGERS
The photo is for representation purposes only and may not be a photo of product being purchased.
Search products similar to 1F85U-22NP
Documents and manuals
WHITE-RODGERS 1F85U-22NP Documents
Overview
Details for 1F85U-22NP
WHITE-RODGERS 80 Series Clear Choice Thermostat (1F85U-22NP)
The WHITE-RODGERS 1F85U-22NP is a digital multistage non-programmable thermostat designed for precise temperature control in residential and commercial applications. Featuring a clear and easy-to-read 5" display, this thermostat offers intuitive operation and advanced functionality.
Key Features:
- Multistage Heating and Cooling: Supports up to two stages of heating and two stages of cooling, providing efficient and precise temperature management.
- Auto Changeover: Automatically switches between heating and cooling modes based on the set temperature and ambient conditions.
- Keypad Lockout: Prevents unauthorized changes to thermostat settings, ensuring consistent temperature maintenance.
- Temperature Limits: Allows for user-defined temperature limits to prevent extreme temperature fluctuations.
- 2H/2C Operation: Supports both 2-wire heating and 2-wire cooling systems, providing versatility in installation.
- Wide Temperature Range: Operates within a temperature range of 45-90°F, suitable for various climates and applications.
The WHITE-RODGERS 1F85U-22NP thermostat is an ideal choice for industrial engineers and maintenance professionals seeking reliable and precise temperature control.
Shop our HVAC supply store today for the best prices and fast shipping on all your industrial product needs!
Emerson 80 Series thermostats offer a footprint that fits the install, features that fit the homeowner and support that fits your business. With a large, backlit display, easy to use design, flexible programming and dependable performance, 80 Series thermostats are the perfect fit for every application.
- Large display, bright backlight, high contrast screen
- Easy to install with built-in level, simple set-up menu and separate subbase
- Non-Programmable
- Dual fuel control, no outdoor sensor required, standard on all staging models
- Auto changeover on all universal models
- Keypad lockout and adjustable heat/cool temperature limits
- 5 year limited warranty for professionals
Specifications
- Program Options
- Non-Programmable
- Program Periods Per Day Options
- None
- Stages
- Universal - Single Stage 1H/1C, Multi-Stage 2H/2C, Heat Pump 2H/1C
- Style
- Horizontal
- Typical Applications
- Gas/Oil/Electric
- 3-Wire Zone Valve Connections
- Yes
- Millivolt Compatible
- Yes
- Economizer Connections
- No
- Humidity Control
- No
- Humidity Control
- RC, RH, C, W/E, W2, Y, Y2, O/B/6, G, L
- Heat Pump Dual Fuel Control
- Yes, No Sensor Required
- Heat Pump Auxiliary Lockout Control - Outdoor Sensor Option
- None
- Remote Sensor Options
- None
- Power Source
- Battery, Hardwire
- Auto Changeover (Heat/Cool)
- Yes
- Fan Option
- Auto, On
- Filter Change Reminder
- No
- Energy Mgt. Recovery/Early Start
- No
- Keypad Lockout
- Total
- Set-Point Temperature Limits
- Yes
- Display Type
- 5 square in.
- Backlight
- Key Press or Continuous with Common Wire
- Voltage
- 20-30 Vac, NEC Class II 50/60Hz
- Battery Power Rating
- mV to 30 Vac
- Amp Rating
- Staging Models: 1.5 A per terminal, 2.5 A maximum all terminals combined; Single Stage Models: 1.0 A per terminal, 1.5 A maximum all terminals combined
